Infrared Ray Cuvettes

Infrared Quartz Cuvettes for Advanced Spectroscopy

Our infrared quartz cuvettes are specifically engineered for near-infrared (NIR) and infrared (IR) spectroscopic applications. Manufactured from high-purity Japanese quartz glass, these cells provide exceptional transmission in the 800nm-3500nm wavelength range, making them ideal for FTIR, pharmaceutical analysis, and chemical research.

Technical Specifications

📊 Wavelength Range

800nm - 3500nm (NIR-IR)

Optimized for infrared spectroscopy

🔬 Path Lengths Available

1mm, 2mm, 5mm, 10mm, 20mm, 30mm, 40mm, 50mm

Multiple options for different sample concentrations

💎 Material Properties

Japanese Synthetic Quartz Glass

Superior IR transmission and chemical resistance

📈 Transmission Rate

>80% (Paired Testing)

High accuracy for quantitative analysis

Infrared Spectroscopy Applications

🏭 Industrial Analysis

  • Polymer characterization
  • Petrochemical analysis
  • Food quality control
  • Environmental monitoring

💊 Pharmaceutical Research

  • Drug purity testing
  • Active ingredient quantification
  • Excipient analysis
  • Stability studies

🔬 Research Applications

  • Molecular structure analysis
  • Reaction monitoring
  • Catalyst characterization
  • Material science research

Path Length Selection Guide for IR Spectroscopy

Path Length Sample Volume Best For Typical Applications Concentration Range
1-2mm 350μL-700μL High concentration samples Organic solvents, concentrated solutions 10-100% concentration
5mm 1.75mL Standard liquid samples Most routine IR analysis 1-50% concentration
10mm 3.5mL Medium concentration samples Aqueous solutions, dilute samples 0.1-10% concentration
20-50mm 7-18mL Low concentration samples Trace analysis, environmental samples 0.001-1% concentration

IR vs UV Cuvettes: Key Differences

Feature IR Cuvettes UV Cuvettes
Wavelength Range 800nm-3500nm 190nm-1100nm
Primary Applications Molecular vibration analysis Electronic transition analysis
Sample Requirements Larger volumes, varied concentrations Smaller volumes, dilute solutions
Path Length Range 1-50mm 1-10mm (typically)
Quartz Cuvettes Sealed Quartz Cell Infrared Four Way Light | NEXACULE - Sealed Cuvettes
Quartz Cuvettes Sealed Quartz Cell Infrared Four Way Light | NEXACULE - Sealed Cuvettes

Quartz Cuvettes Sealed Quartz Cell Infrared Four Way Light | NEXACULE

NEXACULE
$0.00 - $0.00
$0.00
$399.90
$399.90 - $399.90
$399.90
in stock

Description of Quartz Sealed Cell: Type: Cuvettes Sealed Volume:3.5ml Material:Japanese quartz glass Path length:10mm Size:12.5x12.5x62mm T...

View full details
$0.00 - $0.00
$0.00
$399.90
$399.90 - $399.90
$399.90
1.75ml Infrared Quartz Cuvette 5mm Spectrophotometry Cells | NEXACULE - Infrared Ray Cuvettes
1.75ml Infrared Quartz Cuvette 5mm Spectrophotometry Cells | NEXACULE - Infrared Ray Cuvettes

1.75ml Infrared Quartz Cuvette 5mm Spectrophotometry Cells | NEXACULE

NEXACULE
$0.00 - $0.00
$0.00
$55.99 - $79.90
$55.99 - $79.90
$55.99
in stock

Type: Quartz Cuvette  Volume:1.75ml Path length:5mm Transmittance:>80%(Paired testing) Outline dimension:12.5x7.5x45 mm Material：Japanese...

View full details
$0.00 - $0.00
$0.00
$55.99 - $79.90
$55.99 - $79.90
$55.99
7ml Infrared Quartz Cuvette 20mm Spectrophotometry Cuvette | NEXACULE - Infrared Ray Cuvettes
7ml Infrared Quartz Cuvette 20mm Spectrophotometry Cuvette | NEXACULE - Infrared Ray Cuvettes

7ml Infrared Quartz Cuvette 20mm Spectrophotometry Cuvette | NEXACULE

NEXACULE
$0.00 - $0.00
$0.00
$69.90 - $79.90
$69.90 - $79.90
$69.90
in stock

Type: Quartz Cuvette  Volume:7ML Path length:20mm Transmittance:>80%(Paired testing) Outline dimension:12.5x22.5x45 mm Material：Japanese ...

View full details
$0.00 - $0.00
$0.00
$69.90 - $79.90
$69.90 - $79.90
$69.90
18ml Infrared Quartz Cuvette 50mm Spectrophotometry Cuvette | NEXACULE - Infrared Ray Cuvettes

18ml Infrared Quartz Cuvette 50mm Spectrophotometry Cuvette | NEXACULE

NEXACULE
$0.00 - $0.00
$0.00
$129.90
$129.90 - $129.90
$129.90
in stock

Type: Quartz Cuvette  Volume:18ml Path length:50mm Technology:Two polished windows Transmittance:>80%(Paired testing) Outline dimension:1...

View full details
$0.00 - $0.00
$0.00
$129.90
$129.90 - $129.90
$129.90
14ml Infrared Quartz Cuvette 40mm Spectrophotometry Cuvette | NEXACULE - Infrared Ray Cuvettes
14ml Infrared Quartz Cuvette 40mm Spectrophotometry Cuvette | NEXACULE - Infrared Ray Cuvettes

14ml Infrared Quartz Cuvette 40mm Spectrophotometry Cuvette | NEXACULE

NEXACULE
$0.00 - $0.00
$0.00
$85.90 - $99.90
$85.90 - $99.90
$85.90
in stock

Type: Quartz Cuvette  Volume:14ml Path length:40mm Transmittance:>80%(Paired testing) Outline dimension:12.5x42.5x45 mm Material：Japanese...

View full details
$0.00 - $0.00
$0.00
$85.90 - $99.90
$85.90 - $99.90
$85.90
10.5ml Infrared Quartz Cuvettes 30mm Quartz Cells | NEXACULE - Infrared Ray Cuvettes
10.5ml Infrared Quartz Cuvettes 30mm Quartz Cells | NEXACULE - Infrared Ray Cuvettes

10.5ml Infrared Quartz Cuvettes 30mm Quartz Cells | NEXACULE

NEXACULE
$0.00 - $0.00
$0.00
$69.90 - $89.90
$69.90 - $89.90
$69.90
in stock

Type: Quartz Cuvette  Volume:10.5ML Path length:30mm Transmittance:>80%(Paired testing) Outline dimension:12.5x32.5x45mm Material：Japanes...

View full details
$0.00 - $0.00
$0.00
$69.90 - $89.90
$69.90 - $89.90
$69.90
3.5ml Infrared Quartz Fluorescence Cell with Stopper 10mm | NEXACULE - Infrared Ray Cuvettes
3.5ml Infrared Quartz Fluorescence Cell with Stopper 10mm | NEXACULE - Infrared Ray Cuvettes

3.5ml Infrared Quartz Fluorescence Cell with Stopper 10mm | NEXACULE

NEXACULE
$0.00 - $0.00
$0.00
$109.90 - $159.90
$109.90 - $159.90
$109.90
in stock

Type: Quartz Cuvette  Volume:3.5ML Path length:10mm Technology:Fully fution technology Transmittance:>80%(Paired testing) Outline dimensi...

View full details
$0.00 - $0.00
$0.00
$109.90 - $159.90
$109.90 - $159.90
$109.90
Infrared Quartz Fluorescence Cuvette 10mm Cell with Screw Cap | NEXACULE - Infrared Ray Cuvettes
Infrared Quartz Fluorescence Cuvette 10mm Cell with Screw Cap | NEXACULE - Infrared Ray Cuvettes

Infrared Quartz Fluorescence Cuvette 10mm Cell with Screw Cap | NEXACULE

NEXACULE
$0.00 - $0.00
$0.00
$399.90
$399.90 - $399.90
$399.90
in stock

Type: Quartz Cuvette  Volume:3.5ML Path length:10mm Technology:Fully fution technology Transmittance:>80%(Paired testing) Outline dimensi...

View full details
$0.00 - $0.00
$0.00
$399.90
$399.90 - $399.90
$399.90
Infrared Quartz Cuvettes Cells Closed Spectrophotometry Cuvette | NEXACULE - Infrared Ray Cuvettes
Infrared Quartz Cuvettes Cells Closed Spectrophotometry Cuvette | NEXACULE - Infrared Ray Cuvettes

Infrared Quartz Cuvettes Cells Closed Spectrophotometry Cuvette | NEXACULE

NEXACULE
$0.00 - $0.00
$0.00
$99.99
$99.99 - $99.99
$99.99
in stock

Type: Quartz Cuvette  Volume:3.5ML Path length:10mm Transmittance:>80%(Paired testing) Outline dimension:12.5x45x45mm Material：Japanese Q...

View full details
$0.00 - $0.00
$0.00
$99.99
$99.99 - $99.99
$99.99
Infrared Ray Quartz Cuvette Cells Spectrophotometry Cuvette | NEXACULE - Infrared Ray Cuvettes
Infrared Ray Quartz Cuvette Cells Spectrophotometry Cuvette | NEXACULE - Infrared Ray Cuvettes

Infrared Ray Quartz Cuvette Cells Spectrophotometry Cuvette | NEXACULE

NEXACULE
$0.00 - $0.00
$0.00
$59.90 - $99.90
$59.90 - $99.90
$59.90
in stock

Type: Quartz Cuvette  Volume:350ML/700ML/1.75ML Path length:1mm/2mm/5mm Transmittance:>80%(Paired testing) Outline dimension:12.5x45x45mm ...

View full details
$0.00 - $0.00
$0.00
$59.90 - $99.90
$59.90 - $99.90
$59.90
3.5ml IR Quartz Cuvettes 10mm Spectrophotometry Cuvette | NEXACULE - Infrared Ray Cuvettes
3.5ml IR Quartz Cuvettes 10mm Spectrophotometry Cuvette | NEXACULE - Infrared Ray Cuvettes

3.5ml IR Quartz Cuvettes 10mm Spectrophotometry Cuvette | NEXACULE

NEXACULE
$0.00 - $0.00
$0.00
$59.90 - $99.90
$59.90 - $99.90
$59.90
in stock

Type: Quartz Cuvette  Volume:3.5ml Path length:10mm Transmittance:>80%(Paired testing) Outline dimension:12.5x12.5x45 mm Material：Japanes...

View full details
$0.00 - $0.00
$0.00
$59.90 - $99.90
$59.90 - $99.90
$59.90
350ul-1750ul Micro IR Quartz Cuvette Cells with Lid Slit 1-5mm | NEXACULE - Infrared Ray Cuvettes
350ul-1750ul Micro IR Quartz Cuvette Cells with Lid Slit 1-5mm | NEXACULE - Infrared Ray Cuvettes

350ul-1750ul Micro IR Quartz Cuvette Cells with Lid Slit 1-5mm | NEXACULE

NEXACULE
$0.00 - $0.00
$0.00
$89.90
$89.90 - $89.90
$89.90
in stock

Type: Quartz Cuvette  Volume:0.54ml Path length:6mm Transmittance:>80%(Paired testing) Outline dimension:7x8x27mm Technology:Solder frit ...

View full details
$0.00 - $0.00
$0.00
$89.90
$89.90 - $89.90
$89.90

Infrared Quartz Cuvettes for Advanced Spectroscopy

Our infrared quartz cuvettes are specifically engineered for near-infrared (NIR) and infrared (IR) spectroscopic applications. Manufactured from high-purity Japanese quartz glass, these cells provide exceptional transmission in the 800nm-3500nm wavelength range, making them ideal for FTIR, pharmaceutical analysis, and chemical research.

Technical Specifications

📊 Wavelength Range

800nm - 3500nm (NIR-IR)

Optimized for infrared spectroscopy

🔬 Path Lengths Available

1mm, 2mm, 5mm, 10mm, 20mm, 30mm, 40mm, 50mm

Multiple options for different sample concentrations

💎 Material Properties

Japanese Synthetic Quartz Glass

Superior IR transmission and chemical resistance

📈 Transmission Rate

>80% (Paired Testing)

High accuracy for quantitative analysis

Infrared Spectroscopy Applications

🏭 Industrial Analysis

  • Polymer characterization
  • Petrochemical analysis
  • Food quality control
  • Environmental monitoring

💊 Pharmaceutical Research

  • Drug purity testing
  • Active ingredient quantification
  • Excipient analysis
  • Stability studies

🔬 Research Applications

  • Molecular structure analysis
  • Reaction monitoring
  • Catalyst characterization
  • Material science research

Path Length Selection Guide for IR Spectroscopy

Path Length Sample Volume Best For Typical Applications Concentration Range
1-2mm 350μL-700μL High concentration samples Organic solvents, concentrated solutions 10-100% concentration
5mm 1.75mL Standard liquid samples Most routine IR analysis 1-50% concentration
10mm 3.5mL Medium concentration samples Aqueous solutions, dilute samples 0.1-10% concentration
20-50mm 7-18mL Low concentration samples Trace analysis, environmental samples 0.001-1% concentration

IR vs UV Cuvettes: Key Differences

Feature IR Cuvettes UV Cuvettes
Wavelength Range 800nm-3500nm 190nm-1100nm
Primary Applications Molecular vibration analysis Electronic transition analysis
Sample Requirements Larger volumes, varied concentrations Smaller volumes, dilute solutions
Path Length Range 1-50mm 1-10mm (typically)
