You can download a full compatibility chart for thermal analysis crucibles by device brand in PDF. This includes pan sizes, compatible models, and a reference table for volume and weight. Save time and avoid mismatches with this guide.
If you ever lost time searching product catalogs for the right sample pan size, you will know why having a clear compatibility chart matters. I have seen teams frustrated when a new box of pans or crucibles arrives, only to realize the fit is wrong or the cover is not included. One download can solve that. Find your brand, see all supported crucibles, and use the sizing data for quick cross-checks. Now, let’s break down where to find these sheets, what to look for, and how to use the references to make your next thermal analysis run smoother.
Is there a compatibility chart for DSC crucibles?
Have you ever opened a box of sample pans and immediately wondered if they are actually for your model? This uncertainty leads to wasted time in busy labs. Clear information is critical here.
Yes, there are manufacturer-verified compatibility charts for DSC crucibles. These show fit for each major brand and model. You can compare dimensions, recommended pans, and required accessories before you order.
| Brand | Device Model | Recommended Crucible Type | Typical Pan Size (mm) | Notes |
|---|---|---|---|---|
| Mettler Toledo | DSC 1, DSC 3 | Aluminum, high purity | 6.7×2.3 | Flat or deep, pan cover included |
| TA Instruments | Q2000, Q20 | Aluminum, hermetic or standard | 6.52×1.75 | Hermetic pans need special press |
| Netzsch | DSC 204, Setaram | Deep dish aluminum, φ6mm | 6.0×3.0 | Use deep cups for higher volume |
| Shimadzu | DSC-60 | Open aluminum pan | 5.8×1.0 | Must pair with compression cover |
I often see confusion about “crucible” and “sample pan.” Technically, a crucible is a high-temperature vessel, often used in thermal analysis. With DSC and TGA devices, “sample pans” usually mean the same thing for most labs. Trusted charts can help make sure you are never left guessing or reordering the wrong product.
Where can I find sample pan dimension sheets?
Do you wish you had a one-page table with every pan diameter, depth, and part number side by side? Many labs keep these as PDF printouts taped to their instruments.
You can find official pan dimension sheets on manufacturer sites and on trusted lab supply platforms. I share downloadable guides for all major DSC, TGA, and DTA equipment below.
| Brand | Standard Pan Diameter (mm) | Pan Depth (mm) | Material | Find Dimension Sheet |
|---|---|---|---|---|
| TA Instruments | 6.52 | 1.75 | Aluminum, Platinum | Download PDF |
| Mettler Toledo | 6.7 | 2.3 | Aluminum, Sapphire | Download PDF |
| Netzsch | 6.0 | 3.0 | Aluminum, Alumina | Download PDF |
| Shimadzu | 5.8 | 1.0 | Aluminum | Download PDF |
Not all manufacturers publish their full measurement specs. When I need the real numbers, my best tip is to check with a scientific supply company or a trusted product data sheet. Watching for pdf links will save you major headaches on reorders where fit must match down to the hundredth of a millimeter.
Can I download a thermal crucible volume vs. weight reference?
Is your lab always calculating sample size, but never sure how much material fits each pan? This is a common problem, especially when switching between flat and deep dishes.
You can download a simple volume vs. weight calculator sheet for DSC, TGA, and DTA crucibles. These sheets convert mm³ to mg, saving guesswork on sample prep. PDF format available for all main pan types.
| Crucible Type | Volume (mm³) | Max Sample Weight (mg) | Suitable Methods |
|---|---|---|---|
| Flat Pan | 25-45 | 10-30 | Standard DSC, TGA |
| Deep Pan | 55-95 | 40-70 | High volume DSC, Setaram |
| Crucible Cup | 30-150 | 8-120 | High temp DTA, Reaction studies |
The numbers above come from published DSC and TGA studies. It is always smart to check your device’s calibration for each new crucible batch. You will find volume, weight, and method suitability can save sample material and cut human error.
How to select crucibles based on your device brand?
Have you found it tough to buy one batch of pans that works for all your brands and all projects? I have watched labs struggle with stock floods and mix-ups because pan types were not selected by instrument.
The fastest way to select the right sample pan or crucible is by matching both device and model number. Use the compatibility reference chart below. Select pans based on fit, function, and test type, not just size.
| Device Brand | Model | Pan/Crucible to Select | Cover/Accessory Needed |
|---|---|---|---|
| Setaram | LABSYS Evo | φ6mm deep dish aluminum | Yes, with pressure lid |
| Shimadzu | DSC-60/60A | Open aluminum pan | Must use compression cover |
| Netzsch | DSC 204 | Deep well aluminum | Standard or vented lid |
| TA Instruments | Q100/Q200 | Hermetic pan or standard pan | Press tool for hermetic |
If you manage multiple devices, keep an updated inventory of both pans and lids by model. Paying attention to cover requirements is just as vital as pan shape. For example, Shimadzu pans always need press-on covers, while Netzsch deep dishes need lids for high temperature tests. This reference will help you avoid missing critical parts mid-experiment.
